Electrical Copper Cable Unilay Wire 0.05-2.0mm Winding Bunching Buncher Stranding Double Twist Annealing Tinning Extruder Extrusion Making Drawing Machine
1.Single Wire Dia: Φ0.30~Φ0.68mm2.Size of Bobbine : Φ400/Φ500 steel plate3.Heads: according to customer's demand4.Tensio
Basic Info
| Model NO. | FC-300B/400B/500B/650B/800B/1000B/1250B |
| Warranty | 12months |
| Large Loading | Above 50kg |
| Type | Passive Pay off |
| Color | Sky Blue or Apple Green |
| Pay off Bobbin | Dia300/400/500 |
| Heads | 7heads or According Customer′s Requirement |
| Tension Control | Improved Tension Gun Control, Constant Tension |
| Transport Package | Simply Packed |
| Specification | heads can as customer′s requirement |
| Trademark | FC |
| Origin | China Jiangsu |
| HS Code | 8479811000 |
| Production Capacity | 60sets/Month |
Product Description
1.Single Wire Dia: Φ0.30~Φ0.68mm2.Size of Bobbine : Φ400/Φ500 steel plate3.Heads: according to customer's demand4.Tension Control: improved tension gun control, constant tension 5.Brake: automatic brake by friction plate when wire break
| Equipment model | FC-250B | FC-300B | FC-400B | FC-450B |
| Twisting usage | Apply for the bunching of aerospace,medical instrument,cellphone,notebook And ultra fine conductor(above seven pcs of alloy wires,tinned wires,silver jacketed wires and enamelled wires) | |||
| Single wire dia(mm) | 0.03-0.18 | 0.04-0.28 | 0.05-0.32 | 0.05-0.32 |
| Stranding section area(mm2) | 0.0049-0.3 | 0.0088-0.45 | 0.0137-1.0 | 0.0137-1.0 |
| Pitch(mm) | 0.8-10.8 | 1.6-21.6 | 3.1-33.3 | 3.1-33.3 |
| Direction of lay:optional for right or left | ||||
| Take up bobbin | 200-250 | 250-300 | 300-400 | 300-450 |
| Max rotating speed | 4000rpm(8000TPM) | 3500rpm(7000TPM) | 3000(6000TPM) | |
| Main motor power:3.7KW | ||||
| Inverter power:3.7KW | ||||
| Tension control:PLC+touchscreen +magnetic powder clutch,ensure the constant tension from empty to full bobbin | ||||
| Magnetic powder clutch | 0.3kgf | 0.6kgf | ||
| Protection:automatically brake/stop 1)wire inside and outside is broken 2)the preset length is arrived | ||||
| Brake mode | Electromagnetic brake | |||
| Traversing method:rolling wire with ring drive units,winding pitch and width are adjustable | ||||
