High-Quality Core Wire Insulation Extruder Machine

Basic Info

Model NO.	XJ-30mm/40mm/50mm/60mm
Machine Name	Core Wire Insulation Extruder Machine
Screw L/D Ratio	26:1
Motor	Siemens
Inverter	Yaskawa
Electrical Components	Omron, Schneider
Transport Package	PE Film + Wooden Box
Specification	CE SGS
Trademark	NEWTOPP
Origin	China
HS Code	8479400000
Production Capacity	6sets/Month

Product Description

High-quality Core Wire Insulation Extruder Machine1. Application: Suitable for copper conductor single layer insulation extrusion or "single layer + stripe" insulation extrusion.2. Machine Features:1) Used Widely: Suitable for copper conductor single layer insulation extrusion or "single layer + stripe" insulation extrusion;
2) High output: Optimize the design of screw, make it durable, chromeplate non worn down, non conglutination, color-change quickly, high speed, high output.3) High quality: Concentricity:over 93%; OD tolerance:±0.005mm.4) Temperature control precise: Adopted SCR power controller or solid-state relay(SSR) , with imported high-quality temperature control table and copper casting heater,temperature zone of machine controlled within ±1ºC.5) Operate easily: Exclusive adopt NEWTOPP Teflon specialized touch screen, both provide Chinese/English operation interface, auto-control and auto-feedback, operate easily.6) Save place: Intergrate accumulator, capstan, take-up, meter-counter,sparker etc. the total length can be limited within 20M.3. Technical Parameters:

Model	XJ-E30	XJ-E40	XJ-50	XJ-60
Pay-off type	Passive / active type shaftless pay-off
Pay-off bobbin	Φ300-400mm	Φ300-400mm	Φ400-500mm	Φ400-500mm
Screw diameter	Φ30mm	Φ40mm	Φ50mm	Φ60mm
Screw L/D ratio	26:1	26:1	26:1	26:1
Extrusion output	35kg/h	45kg/h	60kg/h	80kg/h
Main power	7.5HP	10HP	15HP	20HP
Wire specification	AWG36-30	AWG32-26	AWG30-24	AWG28-20
Cooling device	U-type single-layer water trough
Accumulate length	0-200m	0-200m	0-200m	0-200m
Capstan power	3HP	3HP	3HP	5HP
Max speed	600m/min	500m/min	400m/min	400m/min
Take-up type	Double shaft	Double shaft	Double shaft	Double shaft
Take-up bobbin	Φ400-500mm	Φ400-500mm	Φ500-630mm	Φ500-630mm
Size( mm)	20000*1500*2100	20000*1600*2100	20000*1700*2100	23000*1800*2103
Total Weight	4.0T	4.5T	5.0T	6.0T

4. Brand of main parts:1) Motor: Siemens2) Driver: Yaskawa 3) Bearing: NSK, NACHI, ASCHI4) Electric components: Omron,Schneider 5) PLC: Siemens5. Safety performances: 1) Switch-off at overpressure2) Disabling signal at under temperatures3) Stop at over temperature3) Motor power limit4) Emergency stop5) Monitoring of tolerances and alarms6) Monitoring of sensors6. Machine pictures:7. Packing and Shipment:8. About usDongguan NewTopp Electrical Machinery is a high-tech enterprise which specializes in developing and manufacturing wire and cable machines, and our main products includes all kind of extrusion production line, single twisting machine, double twisting machine, cantilever stranding machine, cage-type twisting machine, planetary cabling machine, triple-core stranding with back-twist and taping, and single layer/double layer taping machine etc. and our products have passed CE certification and SGS audited , and we also have passed ISO9001:2008 since 2010. 9. Exhibition pictures:10. Customer visiting:11.FAQ:
1) Are you a manufacturer or trading company? We are a manufacturer with more than 10 years manufacturing exprience in cable machinery, and there are total over 6000 spuare meters of production workshop and offices in our factory.2) What is the advantages of your machine compared with competitors? Our automatic control technology is in leading position in wire and cable equipment field. Good cost performance, quality is steady. We combine the equipment and the wire&cable technology, offer you technology assistance.3) How can we get to your factory to see the machines works? Address: No.286 Huai'de road, ,Humen Town, Dongguan City,Guangdong Province,China. Only 40 minutes by car from Shenzhen Baoan International airport to our factory; Only 1.5 hours by car from Guangzhou Baiyun Airport to our factory; Only 17 minutes take high-speed rail from Guangzhou south station to Humen.
12. Contact information:
Contact: Mr.David Hou (Sales Engineer) Mobile: 0086-188 2296 5628
