Automatic Cable & Wire Aramid Armoring Machine

Automatic Cable & Wire Aramid Armoring Machine

Good Quality High Voltage Cable & Wire Aramid Armoring Machine Aramid machine transmission system consists of motor, red
Basic Info
Model NO. Alpha
Application Industrial
Product Name Fiber Optical Cable Aramid Armouring Equipment
Certification CCC, PSE, UL, FDA, RoHS, ISO, CE
Installation Vertical
Driven Type Pneumatic
Mould Life 300, 000-1, 000, 000 Shots
Strand Material Aramid Yarn, Glass Yarn, Water Blocking Yarn.
Winch Speed 100rpm
Aramid off Tension Adjustment Range 4-20n
Aramid Tension Control Mode Magnetic Remanence Brake
Main Motor 7.5kw Variable Frequency Motor
Center Height 1000mm
Max Cable Diameter 5-30mm
Stranding Direction Left or Right
Operation Direction From Right to Left
Transport Package Standard Seaworthy Package
Specification ISO9001
Trademark HLT
Origin Jiangsu, China
HS Code 8544700000
Production Capacity 1000 Sets Per Year
Product Description
Good Quality High Voltage Cable & Wire Aramid Armoring Machine




Main Technical Parameter
Aramid yarn group head 12 or 24 heads
Winch speed100rpm
Aramid off tension adjustment range 4-20N
Center height1000mm
Yarn specification290x 94x 290mm
Max cable diameter5-30mm
Strand materialAramid yarn, glass yarn, water blocking yarn
Stranding directionLeft or right
Operation directionfrom right to left
Aramid tension control modeMagnetic remanence brake
Main motor7.5kw variable frequency motor
ControllerFC302

Aramid machine transmission system consists of motor, reducer, timing belt pulleys and other components,transmission power is transmitted to the stranding body, making the body twist around the centre tube.Stranding pitch is adjusted via level moving within a certain range. Pneumatic brakes installed on the strander, for purpose of shutdown or accident. Electrical control part adopts PLC to establish communication with other devices, single-action, interaction and synchronization.Security guard prevents accidents during aramid machine at high speed.




Aramid Armouring Machine



Aramid Armouring Machine




Machine Detail Picture



Our Factory



Automatic Cable & Wire Aramid Armoring Machine



Package Customer Visiting



Our Team

Automatic Cable & Wire Aramid Armoring Machine


FAQ

-Q:What is aramid machine? A: Aramid machine is used for armoring wire and cable equipment. For armoring non-metallic materials. such as : aramid yarn, glass yarn, water blocking yarn.-Q. What is consist of for Aramid machine? A: Aramid machine consists of rack ,reel, twisted body, transmission device, stranding unit, pneumatic brakes, electrical controls, safety devices and other components. Aramid machine with passive pay-off stand, tension is provided by the hysteresis brake. The tension can be set as required.Number of reel with 12 or 24 is for the user to select. Pay-off reel media through a set of guide wheels and magnetic hole and pooled into the mold at the stranding unit. Optical cable stranding line, Optical fiber cable sheathing line series and other optical cable equipment.− Q: What can we offer our customers? A: Our professional production and technical personnel can train our customers' employees and ensure the smooth production of customers. And will provide our customers with after-sales service.− Q: How long is the machine warranty? A: Warranty period of one year (since the completion of mechanical debugging at the buyer's factory)− Q: Why do I choose your company? A: We have more than 10 years of professional experience in the production of cable machinery, providing high-quality, high-security products. We have an experienced team of skilled workers and engineers. We can support overseas training engineers. We can customize the design, to accept the customer's sample design. We can provide customers with after-sales service.Enable us provide accurate quotation for you, please kindly send the following information: 1. Aramid yarn specification2. Qty of Aramid yarn3. Aramid yarn tension range4. Diameter of cable core5. Hinge pitch range
